Artikelomschrijving
Force direction: compression
Nominal load: 600 N
Assembly type: Direct assembly
Add-on measuring device: Pressure gauge 213.40 (ND63) with drag pointer
Connection location (based on display device): 12:00 clock
Relative linearity error: =±2.5% Fnom (with drag pointer)
Ingress Protection IP: IP65
Definition of the certificate class: with
Material of product: Stainless steel
Material piston: CrNi-steel
Nominal size: 10 cm²
Temperature range: -25…+50°C (Rated temperature range)
Filling liquid: FF1 8 Glycerin / water - 70% / 30%
Technical data acc. to datasheet: FO52.13
test protocol - hydraulic force (in 3-6 step-up depending on measuring range)
English and German
Certificate for: force hydraulic
Pressure force
accuracy: in 3-6 steps up, depending on measuring range
Customs tariff number: 90318080
