Artikelomschrijving
liquid velocity range 0,1...10m/s
display: LC 46x23 mm, illuminated/ adjustable
material electrodes AISI 316L / Liner PFA
field housing material AISI 304, protection rating IP 65 according to EN 60529
electrical connection: 3 x cable gland M16x 1,5
linearity typical 0,2%
outputs
4-20mA active or passive, max. load 500 ohms
pulse: 2 x opto coupler, 24V/20mA
status: opto coupler, ready, error or direction
software: standard, German
Standard process connection (without adapters): aseptic connection according to DIN 11864-2 form A
voltage supply: 9...32V DC
electronics: Standard
Adapterset:
process adapter threaded socket
set (2pc.) DIN11851 for VOLUMTEC
diameter: DN15 PN10
incl. O-Ring-sealing EPDM
