Nominal size: DN 150 / 6"
Flange connection: ANSI B16.5 RF 150 lbs
Body material: 1.4408
Borosilicate glass DIN 7080
Screws: A4-70
Seals:
media side made of Klinger Sil C4400
cover side made of Klinger Sil C4400
- Face-to-face length acc. to DIN EN 558-1 Gr. 1 -
Operating conditions:
Operating pressure: max. 16 bar at 20°C
Operating temperature: -10°C to 175°C
Medium: unknown
The pressure-temperature limits apply
according to DIN EN 1092-1
The design and manufacture was carried out in
in accordance with the AD
2000 regulations and PED 2014/68/EU.
However, the flange connection fits
counter flanges ANSI B16.5 RF 150 lbs.
Commodity code: 90261089
