Connection Size 1/2" BSP
Connection Type Screwed
Material BodyStainless Steel (Austenitic)
Material Standard ASTM A743 CF16Fa
Pressure Class PN25
Range Name MST21H
PMO - Maximum Operating Pressure21 Bar g @ 235°C
PMA - Maximum Allowable Pressure25 Bar g @ 300°C
Minimum Allowable Temperature0°C
Minimum Operating Temperature0°C
Cold Hydraulic Test Pressure38 Bar g
TMA - Maximum Allowable Temperature400°C @ 23 Bar g
TMO - Maximum Operating Temperature235°C @ 21 Bar g
