- Connection: G1/2, G3/4, G1, G1 1/4, G1 1/2
- Flow rate: 8500 ... 27000 l/min
The proportional oil atomizer adds a precise adjustable amount of oil to the compressed air flow. The pressure drop that occurs when air flows through a Venturi nozzle is used to transport oil from the container to the dropper cap. From here the oil drips directly behind the air duct into the proportional valve, where it is atomized. The oil mist component is proportional to the compressed air flow rate.
| Function |
Lubricator
|
| Connection size/pneumatic connection |
G, Module without jumper, without connecting plate |
| Grid size |
90 mm. |
| Mounting position |
±5° |
Minimal current for lubricator
(l/min) |
100 |
Maximum oil capacity
(ml) |
490 |
| Pressure (bar) |
1... 16 |
| Medium |
Compressed air according to
ISO 85731:2010 [7:4:4] |
| Temperature medium (°C) |
-10... +60 |
| Corossion resistance class CRC |
2 |
| UL certificate |
cULus recognized (OL) |
| EU certificate |
EX4, II 2G
c T6 X
II 2D
c 60 °C X |
| Housing |
Cast aluminum |
