PN 16
Stainless Steel
SPECIFICATION
DESIGN
Body consists of two screwed parts. Face to face length according to DIN 3202/F1
CONNECTION
Flange DN 15 up to DN 150, PN 16 drilled.
MOUNTING POSITION
As desired, preferably for horizontal or vertical mounting. Please refer to fl ow direction.
PRESSURE-AND TEMPERATURE RANGE
- 120°C by 16 bar
- 200°C by 13 bar
MATERIAL
Body: Stainless steel 1.4408
Mesh: Stainless steel 1.4401
MESH
1,50 mm (Standard)
0,25 mm (fi ne mesh)
The above information is intended for guidance only and the company reserves the right to change any data herein without prior notice!
