ARI-Armaturen flanged-Bellows shut-off valve FABA-Plus 22.046 DN300,PN16,EN-JS1049,PTFE-soft seal plug

ARI-Armaturen flanged-Bellows shut-off valve FABA-Plus 22.046 DN300,PN16,EN-JS1049,PTFE-soft seal plug
Maintenance-free soft-sealing shut-off valve straight through with flanges. Housing made of ductile cast iron EN-JS1049 with basic primer. Spindle sealing by double-walled stainless steel bellows made of 1.4571. Internal parts made of 1.4021+QT, fine-threaded spindle with externally mounted and rolled thread, flat funnel lubrication nipple, recessed locking device, heat-dissipating bracket cover optimized for attachments made of EN-JS 1049, safety gland, detachable anti-rotation device with indicator, tight-closing, leakage rate A according to EN12266, non-rising metallic handwheel with cathaphoretic coating, retrofittable limit switch in operation, fully insulatable according to Building Energy Act - GEG, TRB 801 No.45, TA-Luft and EN ISO 15848-1 on request, DIN-DVGW registration GAS, overall length according to EN558/1, medium temperature: -10 - +200°C, nominal pressure: PN 16, nominal size: DN300, cone design: PTFE soft-sealing cone, weight: 404 kg, article code: 22046030008.
