Spirax Sarco DN40 MFP14 Pump Only PN16

Automatic, float-controlled liquid pump according to the
displacement principle. Predestined for use in steam plants.
Drive medium: steam, compressed air, or inert gases.
Problem-free use in explosion-proof areas according to ATEX Directive
94/9/EC, Equipment Group II, Category 2
for gases (Zone 1).
For pumping condensate from boiling, without cavitation,
with a required inlet height of at least 0.15 m above the housing cover.
Complete drainage of steam-heated
devices, even under pressure/vacuum conditions possible.
Spring-supported float mechanism
for safe operation, with check valves
and pre-welded flanges for condensate in-
and outflow, drain screw on the housing.
Maintenance and replacement of all functional-
parts by removal of the housing cover in
installed condition possible.
Connections:
- Condensate inlet: DN 40, EN 1092-2
- Condensate outlet: DN 40, EN 1092-2
- Drive steam: Rp , EN 10226-1
- Venting: Rp 1 , EN 10226-1
Pressure class: PN16
Housing material: Ductile iron EN-JS1049
Internal parts: Stainless steel
Check valves: Stainless steel
Pre-welded flanges: Steel
Drive steam: max. 13.8 bar
Temperature: max. 198C
Flow volume: 7 dm3/stroke
Consumption:
- Steam: max. 16 kg/h
- Air: max. 4.4 dm3/s
Performance: according to TIS 5.400.1D
Manufacturer: Spirax Sarco
Type: MFP14
Order number: 4914.040.000
