Spirax Sarco DN15 DP27SY Reducing Valve PN16/25 0.2-3.0 Bar Yellow

pilot-controlled pressure-
reducing valve with spring setpoint-
adjustment for fast and accurate pressure reductions
of steam and compressed air.
Proportional controller with extremely small P-band,
control of the main valve via a pilot-
valve, internal control lines simplify the
installation, pilot valve with integrated,
replaceable dirt screen, slight variation
of the adjustment range by replacing the
adjustment spring.
Connection: Flange DN15
: EN 1092-2
Pressure rating: PN25
Housing material: Spheroidal graphite EN-JS1049
Internal parts: Stainless steel
Control diaphragm: Stainless steel
Main diaphragm: Stainless steel
Kv value: 2.8 m3/h
Adjustment range: 0.2 - 3.0 bar
Operating pressure: max. 17 bar
Temperature: max. 232C
Cone seal: metallic sealing
Manufacturer: Spirax Sarco
Type: DP27SY
Order number: 8732.015.100
